Absorption Chillers
Specification: Steam & Direct-Fired Heat Driven
Thermal energy cooling systems utilizing low-pressure steam, hot water, or natural gas for off-peak energy savings.
Direct Engineering Summary: Absorption Chillers
Steam-fired and direct gas-fired lithium bromide (LiBr) absorption chillers require specialized vacuum-hermetic metallurgy and solution-chemistry expertise rarely found in conventional HVAC shops. Western Mechanical, Inc. (CSLB #618138: C-20) executes LiBr decrystallization recovery, helium mass-spectrometer leak testing, octyl-alcohol/molybdate inhibitor titration, and hermetic canned-pump replacements on Trane Horizon, Carrier 16JB/16LJ, York Millennium, Broad, and Thermax absorbers across SoCal: (661) 251-0111.
Technical Specifications & Engineering Benchmarks
Benchmark Parameter
Engineering Specification
Discipline Classification
SPECIALTY • CSLB #618138 (C-20 HVAC)
Engineering Specification
Steam & Direct-Fired Heat Driven
Supported OEM Platforms
Carrier, York, Trane, Broad U.S.A., Thermax
Service Labor Standard
100% UA Local 250 Union Trained • 0.78 EMR
Emergency Dispatch SLA
< 2 Hours 24/7 Across Southern California • (661) 251-0111
Regulatory Standards
Title 24 Part 6, SCAQMD Rule 1146, HCAI / OSHPD PIN 70
Engineering Scope & Southern California Field Execution
Absorption chillers use heat energy instead of mechanical electricity to drive the refrigeration cycle. Western Mechanical Inc. provides comprehensive maintenance on lithium bromide and ammonia absorption chillers, lithium bromide crystallization recovery, and vacuum integrity testing.
Single-effect and two-stage LiBr absorption chillers paired with hospital cogeneration turbines or waste-steam headers operate under deep sub-atmospheric vacuum (~6 mmHg absolute in the evaporator). Power interruptions blocking dilution cycles, cooling tower water dropping below 65°F abruptly, or tiny air leaks oxidize internal carbon steel and trigger salt crystallization inside the solution heat exchanger—solidifying J-tubes into rock-hard LiBr hydrate.
Rather than cutting open heat-exchanger shells unnecessarily, Western Mechanical applies controlled external steam/thermal jacketing, hot weak-solution bypass flushing, precision specific-gravity hydrometer mapping, and helium mass-spectrometer pinpoint leak repairs on diaphragm valves and sight glasses to restore liquid circulation safely.
When lithium molybdate or lithium chromate corrosion inhibitors deplete, internal hydrogen gas evolves continuously—blanketing absorber tube bundles, destroying heat-transfer film coefficients, and cutting cooling tonnage by 30% to 50% even at full steam input or high-fire burner modulation.
Our C-20 and commercial union specialists extract anaerobic solution samples for laboratory alkalinity/inhibitor titration, rebuild hermetic refrigerant and absorbent canned-motor pumps without breaking vessel vacuum longer than necessary, service automatic purge chambers, and tune low-NOx direct-fired generators per SCAQMD combustion standards.
UA Local 250 Field Protocol & Certified Best Practices
Lithium bromide chemical concentration and inhibitor titration
High-vacuum purge pump servicing and hermetic leak testing
Heat exchanger descaling on steam and hot water generator bundles
Burner modulation and combustion efficiency tuning on direct-fired units
Frequently Asked Questions: Absorption Chillers
What causes crystallization in a lithium bromide absorption chiller?
Crystallization happens when the lithium bromide solution concentration becomes too high or solution temperature drops too quickly, often caused by rapid condenser water temperature drop or power interruptions.
How does Western Mechanical de-crystallize an absorption chiller?
We use controlled steam or heat injection, internal bypass flushing, and chemical titration without damaging internal tube bundles or rupturing rupture discs.
Why are absorption chillers ideal for co-generation and central energy plants?
They utilize waste steam, turbine exhaust heat, or landfill gas to produce high-tonnage chilled water, completely bypassing high peak-hour electrical demand charges from electric utilities.
